Graphene Zinc Epoxy Graphene Zinc ZD6310-Z850
Epoxy Graphene Zinc ZD6310-Z850 is a two-component high-solid heavy-duty anti-corrosion coating composed of special modified resin, pure thin graphene, zinc powder, inorganic filler, solvent, additives, etc. As a primer, it is used for bare steel surfaces that have been blast-cleaned in moderate to severe corrosive environments, such as steel structures, bridges, port machinery, offshore platforms, engineering machinery, storage tanks and pipelines, power facilities, etc. It can be used in conjunction with high-performance paints to further improve the corrosion resistance. It can be used on approved zinc-rich shop primer surfaces; It can be used to repair damaged areas of galvanized parts or zinc silicate primer coatings;
Description
The TNN Development Limited is one of the most reliable manufacturers and suppliers of graphene zinc epoxy graphene zinc zd6310-z850 in China. Please feel free to wholesale customized graphene zinc epoxy graphene zinc zd6310-z850 at low price from our factory. If you have any enquiry about free sample and discount information, please feel free to email us.
Advantage of Epoxy Graphene Zinc
1.Excellent anti corrosion properties, Pure Ultra-slice graphene has the dual functions of flake barrier and activated zinc powder
2.High coverage rate, which can save about 15% of paint compared with conventional epoxy zinc-rich paint
3.Excellent adhesion and high application tolerance
4.Completely replacement of conventional coatings such as epoxy zinc rich with better anti rust performance.
5.Standards-compliant: Meets the performance standard of HG/T5573-2019 "Graphene Zinc Powder Coating"
Physical Constants
|
Item no. |
ZD6310-Z850 |
|
Type |
Two-component |
|
Color |
Dark gray |
|
Gloss |
Matt |
|
Volume solids |
62% |
|
Solid by weight |
≥80% |
|
Density |
2KG/L |
|
Recommended DFT |
60μm-160μm |
|
Theoretical coverage |
0.258kg/㎡ (80μm DFT) |
|
Touch-dry (press dry) |
30 mins (@25°C) |
|
Application methods |
Spray, Brush, Roll |
|
Application conditions |
Temperature 5°C-50°C, humidity <85% |
|
Shelf life |
12 months from the manufacture date (unopened) |
|
Pot life |
4hrs (@25°C) |
|
Induction time |
20mins (@25°C) |
|
Pack |
35(32+3) kgs /kit |
|
Storage |
In a cool and ventilated place |
|
MOQ |
500kgs |
|
Country of Origin |
Jiangsu province, China |
Protective Systems
Protective Systems
Preceding coat: Spray directly on steel surfaces with surface preparation reaching Sa2.5 or St3 level or approved workshop primer surface.
Consequent coat:
2 coats: graphene zinc +Epoxy/Polyurethane/Fluorocarbon topcoat
3 coats: graphene zinc +Midcoat MIO+Polyurethane/Fluorocarbon topcoat
Product application scenarios
